ODOT-MS100T/100G SERIES : 5/8/16 PORT UNMANAGED ETHERNET SWITCH

Product Feature:

  • 10/100 Mbps self-adaption,(Auto-MDI/MDI-X)
  • Supports IEEE 802.3 for 10BaseT
  • Supports IEEE 802.3u for 100BaseT and 100BaseFX
  • Supports IEEE 802.3xfor flow control
  • Supports broadcast storm protection
  • Supports working temperature: -40~85℃
  • 5/8/16 ports unmanaged Ethernet Switches DIN-rail

Product Details

ODOT-MS100T series is a basic plug and play industrial-grade unmanaged Ethernet switch, euqipped with 5/8/16 10/100 MB ports, all ports supports IEEE802.3/802.3u/802.3x, supports broadcast storm protection, adapt to various industrial environment, protection grade is IP20. The product adopts metal sheel and supports 35 mm DIN-rail installation.

ODOT-MS100T series is a basic plug and play industrial-grade unmanaged Ethernet switch, euqipped with 5/8/16 10/100/1000 MB ports, all ports supports IEEE802.3/802.3u/802.3x, supports broadcast storm protection, adapt to various industrial environment, protection grade is IP20. The product adopts metal sheel and supports 35 mm DIN-rail installation.

Technical Characteristics

MS100T

10/100 Mbps self-adaption,(Auto-MDI/MDI-X)

Supports IEEE 802.3 for 10BaseT

Supports IEEE 802.3u for 100BaseT and 100BaseFX

Supports IEEE 802.3xfor flow control

Supports broadcast storm protection

Supports working temperature: -40~85℃

5/8/16 ports unmanaged Ethernet Switches DIN-rail

MS100G

10/100/1000 Mbps self-adaption,(Auto-MDI/MDI-X)

Supports IEEE 802.3 for 10BaseT

Supports IEEE 802.3u for 100BaseT(X)

Supports IEEE 802.3z for 1000BaseT

Supports IEEE 802.3xfor Flow Control

Supports broadcast storm protection

Supports working temperature: -40~85℃

5/8/16 ports unmanaged Ethernet Switches DIN-rail

ODOT-MS105T: 5-port 10/100Mbps, 35mm DIN-rail

ODOT-MS108T: 8-port 10/100Mbps, 35mm DIN-rail

ODOT-MS116T: 16-port 10/100Mbps, 35mm DIN-rail

ODOT-MS105G: 5-port 10/100/1000Mbps, 35mm DIN-rail

ODOT-MS108G: 8-port 10/100/1000Mbps, 35mm DIN-rail

Technical Parameters
